Camera
|
|
Model
|
FS-318N20/50L/ FS-608N20/50L
|
|
Effective pixels
|
2MP/5MP Optional
|
|
TV System
|
PAL/NTSC
|
|
Video output
|
AHD/TVI
|
|
S/N
|
≥50dB
|
|
Gamma correction
|
0.45
|
|
Focus Length
|
2.8mm/3.6mm Optional
|
|
IR Distance
|
30M
|
|
AES
|
Yes
|
|
AGC
|
Yes
|
|
D&N
|
Ext(default)/Auto / Color / B&W(OSD control)
|
|
BLC
|
Auto
|
|
DNR
|
3DNR
|
|
DWDR
|
Support
|
|
Flicker less
|
ON / OFF
|
|
Weatherproof Housing
|
Yes
|
|
Electrical protection
|
Yes
|
|
Working temperature
|
-20℃ --- 50℃
|
|
Storage temperature
|
-30°C~60°C
|
|
Humidity
|
20%~90%
|
|
Operating voltage
|
DC12V
|
|
DVR
|
|
Model
|
FS-6316PLUS
|
|
Operation system
|
Embedded LINUX operation system
|
|
System resources
|
Multichannel real time record
|
|
Multichannel real time playback
|
|
multichannel multi-user on network operation
|
|
Operation system
|
graphic menu operation interface, support mouse to operate
|
|
Image display
|
1/4/6/9/16 screen
|
|
Language
|
English, traditional Chinese, simplified Chinese, Japanese, Russian, German, Italian, Turkish, polish, Spanish, Korean,Indonesian, Thai, Arabic, Persian, Vietnamese, French, Portuguese,Greek, Czech
|
|
Image coding
|
H.264/H.265
|
|
Surveillance quality
|
VGA(Max 1080P)；HDMI(Max 1080P), CVBS optional
|
|
Preview
|
16*5MP-N@20fps/4*4MP-N@25fps/4*1080P@25fps
|
|
Code capacity
|
16*5 MP-N@12fps/4*4MP-N@17fps/4*1080P@15fps
|
|
Decode capacity
|
16*5 MP-N@12fps/4*4MP-N@17fps/4*1080P@15fps
|
|
Various mode input
|
Coaxial: 16*5MP-N
|
|
Mixed: 4MP-N(coaxial)+1080P (IP) Arbitrary combination for coaxial and IP hybrid mode
|
|
IP: 8*5MP, 16*5MP for all IP mode
|
|
Recognize method
|
Automatic Identification、All AHD、All TVI、All CVI、Customized
|
|
Motion detection
|
192（16*12） testing areas can be set for each image；
|
|
can set multi-sensitivity (only for local channel and P6S IP camera)
|
|
Audio compression
|
G.711U
|
|
Audio output
|
HDMI, support extended audio output.
|
|
Audio Input
|
Can extend to 4ch audio In.
|
|
intercom
|
Support extend audio in and out intercom
|
|
coaxial audio
|
Support 4ch coaxial audio
|
|
Video mode
|
manual>alarm>dynamic testing>timing
|
|
Local playback
|
1CH (5MP-N coaxial input)/4CH (4MP-N coaxial input)
|
|
2CH (Coaxial or Hybrid mode);
|
|
4ch IP mode
|
|
Record retrieval
|
Time retrieval, event retrieval, Timeline retrieval, channel retrieval、Face playback, Intelligent playback(Motion detection playback)
|
|
Occupation
|
1080P 10-15G/day*channel; 720P 10G/day*channel; 960H 6-10G/day*channel;Audio:691.2M/day*channel
|
|
Record storage
|
Local hard disk; network
|
|
Backup mode
|
Network backup、USB , SATA record
|
|
Type
|
IE/mobile/VMS
|
|
P2P
|
Support(IOS, Android, PC)
|
|
APP
|
Multi-screen surveillance; audio surveillance; mobile record; snap; pan-tile control; remote record playback
|
|
Camera OSD control
|
Support
|
|
Pan-tilt control
|
Don’t support
|
|
3D-NR
|
Support auto/manual setting for noise reduction parameters
|
|
Video input
|
16ch BNC; support coaxial audio in
|
|
Video output
|
1ch VGA，1ch HDMI; 1ch TV output(Optional)
|
|
Audio output
|
HDMI output
|
|
Network port
|
RJ45 10M/100M Self-adapt to Ethernet interface
|
|
USB port
|
2 USB 2.0 port
|
|
HDD port
|
1 SATA Port（Can support 8T HDD）
|
|
Wifi port
|
NO
|
|
Remote control
|
Optional
|
|
Power
|
12V/4A（Sufficient amperes）
|
|
Consumption
|
< 15W（exclusive hard disk）
|
|
Temperature
|
-5 °C~ +55 °C
|
|
Working humidity
|
10%~90%
|
